VAPE Ignition - KTM 2-Stroke DC

electronic ignition system for KTM 2-Stroke engines (not Sachs engines)

Magnet based generator / electronic ignition for most 2 stroke KTMs, for 90mm baseplate, has clockwise rotation and is mounted on RH side of engine.
Light output 12V/100W DC. Replaces original Magneto as well as all ignition parts. Does not require any modifications on crankcase.
Fits KTM types 51, 52, 54, 510, 520, 530, 540, 541, 542, 550, 560, 562, 501, 502, 543, 544, 545, 555, 565.

Note:
- does not support Power Valve system
- Does not support electrical starter
- On some KTM models the "GS" cover will not suit with our rotor and you have to use the "cross" cover instead


Advantages:

• all parts are new
• more light output
• very stable ignition with solid spark
• high energy CDI spark
• advance control for 2 stroke offroads (small cc engines of 125-250cc)

Techical Infos for 2 stroke KTM types, DC

	Wiring Diagram
	Installation tips
